Aluminium Liquid Filtration Fiberglass Fabric Cloth Roll

As one of the leading fiberglass filter cloth suppliers and filter cloth manufacturers, Cangchen has developed this innovative aluminium filter fabric to meet the highest industry standards. Aluminium Filtration Fiberglass Fabric by Cangchen is a top-tier solution for all your filtration needs. Our product combines the exceptional filtering properties of fiberglass filter cloth with the enhanced durability and versatility of aluminum filter material. Engineered with precision, this fabric offers superior filtration performance, making it ideal for a wide range of applications.

The white fiberglass filter cloth is supplied in soft, uncoated rolls, making it easy for customers to cut the material into the required width, length or shape according to their own filtration equipment and production process. It is particularly suitable for aluminum foundries that prefer to purchase filter material in bulk rolls and perform cutting or installation directly at the production site.

Aluminium filtration fiberglass fabric roll is woven with special high-twist & high-strength alkali-free fiberglass and special post-treatment. The maximum temperature resistance can reach 900 ℃.

New patented product "smokeless and odorless filter mesh" will gradually replaces similar products to removal of non-metallic inclusion in metal melt is of great technical and economic value to improve the yield of castings and the quality of castings.

Fiberglass Filter Cloth Roll Specifications

White Soft Fiberglass Filter Cloth Supplied in Rolls

Unlike pre-cut fiberglass filter mesh, this product is supplied as continuous roll material.

The white fiberglass fabric has no resin coating, so it remains soft and flexible. Customers can purchase full rolls and cut them locally according to the dimensions required by their launders, holding furnaces, casting tables or other filtration positions.

This supply format is especially suitable for:

● Aluminum plants using different filter dimensions on the same production line

● Customers that cut fiberglass filter material in-house

● Distributors purchasing standard rolls for local resale

● Foundries requiring flexible filter dimensions

● Buyers seeking lower packaging and processing costs compared with individually pre-cut pieces

Roll width, roll length and mesh opening can also be customized according to purchasing requirements.

Aluminium filtration fiberglass fabric roll is widely used in automobile and motorcycle wheels, cylinder pistons, aluminum rods, aluminum materials, aluminum ingots, aluminum plates and precision casting of all types of aluminum alloy casting.

Effectively remove impurities, reduce turbulence and eliminate air bubbles, thereby improving the quality of castings and reducing costs.

At the same time does not pollute the aluminum liquid and affect the chemical properties of the metal. Therefore, aluminum waste containing the filter mesh, aluminum liquid from sprue and the riser can be directly returned to the furnace for remelting, greatly reducing costs.

Fiberglass Filter Cloth Roll for Molten Aluminum Filtration Functions

1. Low cost and easy to use

2. Improves fluidity and metal distribution

3. Removes micron sized inclusions and impurities

4. Can be used with existing pattern equipment

5. Reduce turbulence

6. Minimize gating system to reduce cost

Aluminium Filtration Fiberglass Fabric Roll Key Points of Usage

1. Use area of filter net: F1 = F2 / AxB

● F1: the cross-sectional area of the casting system.

● F2: the original cross-sectional area of the casting system.

● A: the porosity of the filter screen, generally 50-60%.

● B: the filtration rate of filter screen, generally 60-80%.

Therefore, the cross-sectional area of the casting system is generally 2-4 times that of the casting system without the casting net.

2. Position of filter screen:

● Place the filter under the sprue cup;

● Placed on the parting surface under the sprue;

● Three different positions on the lap surface of the runner.

Crafted from premium-quality fiberglass, our filtration fabric is woven with utmost care to ensure excellent strength and durability. This ensures that our aluminium filter fabric can withstand rigorous operating conditions while providing efficient filtration results. The incorporation of aluminum fabric adds further stability and longevity to the product, allowing for prolonged usage without compromising on performance.

The aluminium filter mesh integrated into the fabric enhances the filtering capabilities, enabling the efficient removal of contaminants, dust, and particles from air or liquid streams. Its fine mesh structure ensures a high capture efficiency, ensuring that your filtration process is thorough and reliable. Whether you need to filter air in HVAC systems, purify water, or enhance industrial processes, our aluminium filtration fabric is up to the task.

In addition to its exceptional filtering properties, our fibreglass filters also boast excellent chemical resistance, making them suitable for use in demanding environments. The fabric's resistance to corrosion and chemicals ensures that it remains effective and reliable even when exposed to harsh substances.

Cangchen's Aluminium Filtration Fiberglass Fabric offers a cost-effective solution that saves both time and money. Its long lifespan and low maintenance requirements make it a wise investment for businesses seeking quality and efficiency.

Choose Cangchen as your trusted supplier of aluminium filter fabric, and experience the superior performance and reliability of our products. Contact us today to discuss your specific filtration requirements and let our team of experts assist you in finding the perfect solution for your needs.

Applications of Fiberglass Filter Cloth Roll

Our fiberglass filter cloth roll is mainly used for filtration of molten aluminum and aluminum alloys.

Typical applications include:

Aluminum Launder Filtration

The filter cloth can be installed in molten aluminum launders to remove inclusions while aluminum is transferred between melting, holding and casting equipment.

Holding Furnace and Sprue Filtration

Fiberglass filter cloth can be positioned at suitable filtration points around holding furnaces and sprues to improve melt cleanliness before casting.

Aluminum Ingot Production

Suitable for filtration during aluminum ingot casting where continuous molten metal flow requires an economical filtration medium.

Aluminum Billet and Rod Casting

The roll material can be cut according to the dimensions of filtration systems used in aluminum billet and rod production.

Aluminum Sheet and Strip Production

It can also be used in continuous casting operations for aluminum sheet, strip and related semi-finished products.

Cangchen is a manufacturer specializing in filtration products for foundry and molten metal applications. Our fiberglass production facility uses more than 100 weaving machines and supports the production of fiberglass filter cloth, fiberglass filter mesh, cap filters, TF combo bags and customized filter products. We also provide specification and OEM customization for foundries, distributors and private-label customers.

For fiberglass filter cloth rolls, we can support:

● Custom roll width and length

● Different mesh openings

● Different fabric weights and thicknesses

● Bulk order production

● OEM and private-label requirements

● Samples for product evaluation
